Product Details:
|
| Sine Force Peak: | 6KN | Max Acceleration: | 100 G |
|---|---|---|---|
| Max Velocity: | 200 Cm/s | Frequency Range: | 2-3000 Hz |
| Max Displacement: | 51 Mm | Power Supply: | 3-phase AC 380V / 50Hz |
| Highlight: | shaker testing device,vibration table testing equipment |
||
Shaker Testing Device Vibration Testing Machine for Lithium Battery Safety Testing
Vibration Testing Machine Specifications: EV340-EV450
| Model | EV340 | EV350 | EV420 | EV430 | EV440 | EV450 |
| Vibration Generator | VG4000/76 | VG5000/76 | VG2000/100 | VG3000/100 | VG4000/100 | VG5000/100 |
| Frequency(Hz) | 2-2500 | 2-2500 | 2-3000 | 2-2500 | 2-2500 | 2-2500 |
| Max Exiting Force(kg.f) | 4000 | 5000 | 2000 | 3200 | 4000 | 5000 |
| Max. Displacement (mmp-p) | 76 | 76 | 100 | 100 | 100 | 100 |
| Max. Acceleration(g) | 80 | 100 | 90 | 71 | 66 | 71 |
| Max. Velocity(cm/s) | 200 | 200 | 200 | 250 | 250 | 250 |
| Payload(kg) | 1000 | 1000 | 500 | 500 | 800 | 1000 |
| Armature Mass(kg) | 50 | 50 | 23 | 45 | 60 | 70 |
| Armature Diameter(mm) | φ440 | φ440 | φ320 | φ400 | φ445 | φ445 |
| Cooling Method | Forced Air Cooling | |||||
| Vibration Generator Weight(kg) | 3500 | 3800 | 2000 | 3200 | 4200 | 4500 |
| Vibration Generator Dimension L*W*H(MM) | 1100*1300*1520 | 1100*1300*1520 | 850*1000*1100 | 1100*1300*1440 | 1100*1300*1520 | 1100*1300*1520 |
| Power Amplifier | Amp55k | Amp70k | Amp25k | Amp40k | Amp60k | Amp70k |
| Cooling Method | Forced Air Cooling | |||||
| Power Amplifier Weight(kg) | 800 | 900 | 550 | 600 | 800 | 900 |
| Power Amplifier Dimension L*W*H(MM) | 800*550*1920 | 800*550*1920 | 800*550*1920 | 800*550*1920 | 800*550*1920 | 800*550*1920 |
| Utility Requirements |
3-phase AC380V ±10% 50Hz | |||||
| Aggregate Capacity(KW) | 80 | 90 | 45 | 64 | 85 | 85 |
Vibration Testing Machine Features:
The electromagnetic vibrator is associated by the shaker, high power amplifier and multi-functional controller. If conforms to all military, national and commercial vibration testing specifications and is an essential tool for modernized product design, production, QC & QA works. Using it would make your product be the best. The vibration response bandwidth is big and control precision is high; able to simulate all waveforms and specifications; easy to control; good extendibility and easy to maintain.
The purpose of vibration testing is to make a series of controllable vibration simulation in lab, no matter generated by natural or man-made vibration environment; such as waves, tidal flaps, wind, earthquake or rain and so on. It is to test if the product is capable of sustaining the vibration environment exerted from transporting or usage along its effective life cycle; and certify the standard of design & functional requirement of product. The value of vibration testing is to confirm the reliability of products and effectively screen out the bad products in factory; avoiding damages occurred at arrival; and to assess the failure analysis on the non-performing products; expecting to reach a high standard, high-reliability products. The vibration test stresses on the continuity and fatigue; and contributes to the understanding of product’s status under vibration circumstance in a normal environment; and avoids the product’s unpredictable damage caused under certain vibrating frequency for a long time.
Warranty: 12 months from delivery, lifelong time maintainance.
After-sale service: feedback within 4-8 hours after get the call or email.
Service: OEM, ODM
Certificate: China official third-party calibration report / CE Certification
Welcome to contact us with your vibration test inquiry.
Vibration Testing Machine IImages
