Vertical / Horizontal Vibration Shaker Machine For Battery Vibration Test

China Vertical / Horizontal Vibration Shaker Machine For Battery Vibration Test supplier
Vertical / Horizontal Vibration Shaker Machine For Battery Vibration Test supplier Vertical / Horizontal Vibration Shaker Machine For Battery Vibration Test supplier

Large Image :  Vertical / Horizontal Vibration Shaker Machine For Battery Vibration Test

Product Details:

Place of Origin: Dongguang, China
Brand Name: LABTONE
Certification: CE / ISO
Model Number: EV420

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Case with Vacuum Packing
Delivery Time: 45 Working Days
Payment Terms: T/T, L/C
Supply Ability: 15 Sets / Month
Contact Now
Detailed Product Description
Product Name: Vibration Shaker Machine Max. Velocity: 200 Cm/s
Maximum Displacement: 100mmp-p Frequency Range: 2-3000 Hz
Payload: 500 Kg Power Amplifier: 3-phase AC 380V 50Hz
Rated Force: 20 KN

Vertical And Horizontal Vibration Shaker For Battery Vibration Test With MIL-STD Standard




Main Features



  • Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability
  • Load center airbag has high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation
  • High efficiency D class power switching, 3-sigma peak current, provide finest power consumption and minimize harmonic distortion
  • Quick self-diagnosis with safety interlock, high safety reliability
  • Airbag shock isolation device for vibration platform without the need of additional foundation, perfect reproduction of vibrational wave and reduce vibration transmittance
  • Provide horizontal and vertical expansion platform for different application
  • Simple controller operation





Specifications



Model EV340 EV350 EV420 EV430 EV440
Vibration Generator VG4000/76 VG5000/76 VG2000/100 VG3000/100 VG4000/100
Frequency(Hz) 2-2500 2-2500 2-3000 2-2500 2-2500
Max Exiting Force(kg.f) 4000 5000 2000 3200 4000
Max. Displacement (mmp-p) 76 76 100 100 100
Max. Acceleration(g) 80 100 90 71 66
Max. Velocity(cm/s) 200 200 200 250 250
Payload(kg) 1000 1000 500 500 800
Armature Mass(kg) 50 50 23 45 60
Armature Diameter(mm) φ440 φ440 φ320 φ400 φ445
Cooling Method Forced Air Cooling
Vibration Generator Weight(kg) 3500 3800 2000 3200 4200
Vibration Generator Dimension L*W*H(MM) 1100*1300*1520 1100*1300*1520 850*1000*1100 1100*1300*1440 1100*1300*1520
Power Amplifier Amp55k Amp70k Amp35k Amp40k Amp60k
Power Amplifier Weight(kg) 800 900 550 600 800
Power Amplifier Dimension L*W*H(MM) 800*550*1920 800*550*1920 800*550*1520 800*550*1920 800*550*1920
Utility
Requirements
3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW) 80 90 45 64 85





Standards: MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.




Application: Automotive, Electronics, Aerospace, Vessel, Telecommunication, Photoelectronics, Instrument etc.





Service



Pre-Sales Service



1)Technical consultation: test method, laboratory planning and suggestion.

2)Equipment selection: selection scheme, FAQ.

3)Product testing scheme.

4)Customer communication and progress report.



After-Sales Service



1)Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.

2)Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.

3)Technical support: special paid services are provided according to customer’s needs.





Details



Vertical / Horizontal Vibration Shaker Machine For Battery Vibration Test
