Low Cost Precision Drop Tester Meets ASTM, TAPPI, ISO, JIS And ISTA Standards
Product description
High Accuracy Drop Tester for Packaged Freight Description & Application
Packaging drop tester is used to measure the dropping impact incidence when the package in using, transportation and decorating.
Labtone "1G+" project strictly ensures accuracy. Besides precision plane drop testing, it also can undertake edge and angle test to ensure the complete performance evaluation for the package.
High Accuracy Drop Tester for Packaged Freight Specifications
| Model |
DT150 |
DT200 |
| Drop height range (mm) |
300---1500 |
300----2000 |
| Specimen max.weight (kg) |
85 |
85 |
| Specimen max. size (mm) |
800*800*800 |
800*800*800 |
| Drop mode |
Freedom |
| Machine Dimension (mm) |
1500*1000*2150 |
1700*1200*2750 |
| Machine weight (kg) |
480 |
550 |
| Power supply |
AC220V 50Hz compressed air 0.5~0.7Mpa |
| Standards |
ISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27
|
Functions and Features
1 Satisfy and even beyond GB, IEC, ASTM, ISTA, and other industrial standards.
2 Can perform surfaces, corner, and edge drops.
3 Precise guiding system and pneumatical driving;
4 Unique swing arm structural design, escape acceleration of swing arm greater than 3G.;
5 With double column guide, the hydraulic buffer will absorb the dynamic force of the swingarm, such that the movement is stable, reliable with low noise
6.Self-locking screw-in lifting mechanism to prevent accidental downward glide.
7.Automatic pneumatic interlocks to prevent abnormal detachment of swing arm.
8.Extensible support bracket and steel base plate.
Packaging
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency, etc
FAQ
1. Q: What is your warranty?
- 12 months of product warranty. Free components will be provided if any performance failure occurs within 12 months caused by non-human damage.
2. Q: How-to video provided?
- Yes, if required, our engineers will record a specialize how-to video for you.
3. Q: Is the machine-made in your own plant?
- Yes, welcome to visit our plant(factory), also we support OEM and ODM.
4. Q: What about the quality?
- Each instrument must be carried out 100% quality examination and test when shipping and delivery goods.
- All of our machines are strictly according to CE & ISO standards.
