Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing

Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing
Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing

Large Image :  Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing

Product Details:
Place of Origin: CHINA
Brand Name: LABTONE
Certification: CE, ISO
Model Number: SKT30
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: Negotiable
Packaging Details: International wooden case
Delivery Time: 45 working days
Payment Terms: T/T
Supply Ability: 15 Sets / Month

Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing

Description
Table Size: 40*40 (CM) Max. Specimen Weight: 30 Kg
Max. Acceleration: Half Sine: 600G Machine Dimension: 120*110*245 (cm)
Controller Cabinet Dimension: W55*D50*H80 (cm) Machine Weight: 1900 (Kg)
High Light:

shock and drop testing

,

vibration and shock testing



Mechanical Shock Test Machine With Payload 30kg For Automotive And Battery Test





Product description

Shock tests accurately measure the fragility of products and evaluate how they respond to specific shock inputs. Shock test data is key information when determining if your product is capable of withstanding its intended distribution and use environment.


High Speed Shock Test Systems were developed to achieve the most demanding defense, aerospace, and electronics shock testing specifications. These highly specialized shock systems can generate incredible impact velocities.





Specifications



Model SKT30 SKT50 SKT100 SKT200 SKT300 SKT600
Table size (cm) 40*40 50*60 70*80 100*100 120*120 150*150
Maximum Specimen Weight(Kg) 30 50 100 200 300 600
Max acceleration(G) half sine 600 600 600 500 500 300
saw-tooth waveform 100 100 100 100 100 100
square 150 150 150 150 100 100
Pulse Duration (ms) half sine 40—0.2 40~1 40~1 30~2 20~3 20~3
saw-tooth waveform 18~6 18~6 18~6 18~6 18~6 18~6
square   30~6 30~6 30~6 30~6 30~6
Machine Dimension(cm) 120*110*245 130*140*260 130*120*260 150*130*260 200*160*300 230*180*310
Controller cabinet Dimension(cm) W55*D50*H80
Machine Weight(Kg) 1900 2300 3200 4200 8500 15500
Utility 3-phase AC380V 50/60Hz 0.5~0.8MPa
Requirements
Conforming standards GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL




Shock test System Block Diagram

Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing 0


Company profile:



Labtone Test Equipment Co., Ltd. is a +15 year China manufacture of reliable, cost-effective equipments. Our superior products mainly include: Vibration Test Systems, Shock Test Systems, Bump Test Systems, Drop Tester, Packaging Transportation Simulators, and Combined Environmental Test Chambers.



Labtone started business in 2002 in a plant located in Shenzhen and moved to our new, expanded 6,000 square meter facility in Dongguan, Guangdong in 2015. Today, our products are found around the world in electronics, automotive, aerospace, telecommunication, optoelectronics instrument and industrial machinery applications. Our experience and commitment to new product development has resulted in products that are easy to use, accurate and designed for decades of service.



Labtone products carry a one-year(12months) warranty. We provide comprehensive factory services and supports, technical literatures, manuals and guides as well as having qualified staffs and experts to solve your problems.

We sincerely invite you to visit our factory.


Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing 1



Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing 2




Mechanical Shock Test Equipment With Payload 30kg For Automotive And Battery Testing 3
