Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard

Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard
Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard
Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard

Large Image :  Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard

Product Details:
Place of Origin: CHINA
Brand Name: LABTONE
Certification: CE, ISO
Model Number: DT020
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: International wooden case
Delivery Time: 30-35 working days
Payment Terms: T/T
Supply Ability: 15 Sets Per Month
Contact Now

Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard

Description
Drop Height:: 0-1200mm Package Weight:: 300kg
Package Size:: 1200*1200*1200mm Drop Mode:: Free Fall Drop
Machine Weight:: 2300kg Machine Dimension:: 2100*1700*2800mm
Power Supply:: AC220V 50Hz Warranty:: 12 Months
Highlight:: Package Testing Services, Drop Test Equipment
Highlight:

Consumer Electronics Drop Tester

,

ISTA Standard Drop Tester

,

Packaging Drop Tester

Description

For large packaging with high mass, the vertical drop height during transport will be low and therefore they need drop test with relatively low drop height. Zero Height Drop Tester is mainly used for drop test of big package.
It uses an E-shaped fork that can move downward quickly as a bracket and specimen is placed in balance according to test requirement (surface, edge or Corner drop test). During testing, the bracket moves downwards quickly ahead of specimen with acceleration greater than 3G to ensure the separation of bracket and specimen and achieve free fall. The standard fall distance is ranged between 2.54cm-120cm.




Specifications

Model DT020 DT030 DT050
Drop Height(mm) 0~1200 0~1200 0~1200
Payload Capacity(kg) 200 300 500
Package Size(mm) 1700*1500*1200 1900*1500*1200 1900*1500*1200
Drop Mode Free Fall Drop
Machine Size(mm) 2100*1700*2800 2100*1700*2800 2100*1700*2800
Machine Weight(kg) 2350 2500 3200
Power/Air Supply 3-phase AC380V 50Hz (Compressed Air) 0.5~0.7Mpa
Applicable Standards ISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27





Operating Principle



The machine will move the drop platen which carrying the package under test to the set height, then freely fall the package at flat, edge and corner position. During test, the platen will drop at large than 1G acceleration to ensure the package performs free fall condition.

Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard 0

Equipment Configuration



No. Equipment name Model Qty. Description
1 Drop tester DT030 1 set
2 Pneumatic–hydraulic pressure cylinder   1 pcs
2 Controller   1 set
3 Edge and Corner Auxiliary Fixture   1 set
4 Connection cable   1 set



FAQ:


1. How to you attach the hardware you're testing to your shaker?

By means of a fixture, usually aluminium or magnesium for lightness coupled with rigidity. They can be cast, or smaller fixtures machined from solid stock. Most fixtures are welded.



2. How do you control shakers?

If we're looking for resonances in the product we're testing, we command the shaker to shake the product at one frequency at a time but to vary that test frequency, to sweep it over a range of frequencies. But more realistically, we command the shaker to vibrate randomly and to excite all the resonances simultaneously. Control commands go into the keyboard of a specially programmed computer.



3. What are those resonances? Are they bad?

Have you ever noticed the steering wheel moving with rather a large displacement amplitude, larger than the input to the column? That magnification is called resonance. Possibly it annoys you. There's a slight chance that in a few years that whipping of the steering column might cause bending fatigue failure. When we shake an automotive or ship orland vehicle instrument, we're looking for, for example, portions of printed wiring boards (PWBs) responding with greater motion than we're inputting. That flexing may damage PWB wiring, it may damage the attached components and the PWB.



Service



Pre-Sales Service

  • Technical consultation: test method, laboratory planning and suggestion.
  • Equipment selection: selection scheme, FAQ.
  • Product testing scheme.
  • Customer communication and progress report.

​In-sales

  • Customer communication and progress report.
  • Guidance for pre-installation preparation, equipment commissioning and test run.
  • Calibration (when third party's verification is required).

After-Sales Service

  • Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.
  • Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.
  • Technical support: special paid services are provided according to customer’s needs.


Product

Zero Height Drop Tester For Packaging Testing Of Consumer Electronics With ISTA Standard 1
