Product Details:
|
| Drop Height: | 300-2000mm | Specimen Weight: | 85kg |
|---|---|---|---|
| Specimen Dimension: | 800*800*800mm | Drop Mode: | Freedom |
| Machine Dimension: | 1700*1200*2750mm | Machine Weight: | 550kg |
| Warranty: | 12 Months | Air Pressure: | 0.5-0.7Mpa |
| High Light: | free fall drop test equipment,impact test equipment |
||
FedEx Drop Testing Machine with 85kg Payload, Drop Height 2 Meter Free Fall Drop
Labtone "1G+" project strictly ensure the accuracy. Besides precision plane drop testing, it also can undertake edge and angle test to ensure the complete performance evaluation for the package.
Specifications
| Model | DT150 | DT200 |
| Drop height range (mm) | 300---1500 | 300----2000 |
| Specimen max.weight (kg) | 85 | 85 |
| Specimen max. size (mm) | 800*800*800 | 800*800*800 |
| Drop mode | Freedom | |
| Machine Dimension (mm) | 1500*1000*2150 | 1700*1200*2750 |
| Machine weight (kg) | 480 | 550 |
| Power supply | AC220V 50Hz compressed air 0.5~0.7Mpa | |
| Standards | ISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27 |
|
Functions and Features
1 With upper and lower displacement limit, safety and reliability;
2 Lifting height can be adjusted arbitrarily to meet the needs of different users;
3 Zero freely-drop test stand adopts the double-rail guiding device for stable and reliable lifting operation;
4 The freely-drop test stand can achieve the clamping fall tests for surface, edge and corners of specimen at different direction;
5 The machine is only needed to be placed on the flat marble or concrete ground for installation, without special foundation.
1. Q: What is your warranty ?
2. Q: How-to vedio provided ?
3. Q: Is the machine made in your own plant ?
4. Q: What about the quality ?
