High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber

High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber
High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber

Large Image :  High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber

Product Details:
Place of Origin: China
Brand Name: LABTONE
Certification: ISO,CE
Model Number: HVT1000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood Case with Vacuum Packing
Delivery Time: 45-60 Work Days
Payment Terms: T/T
Supply Ability: 15 Sets / Month

High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber

Description
Name: High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber Vibration Exciting Froce: 300kg.f~5000kg.f
Chamber Dimension(inside): 500*750*600, 600*850*800, 1000*1000*800,1000*1000*1000 Mm Temprature Range: -70~+150℃(Max)
Humidity Range: 20~98%R.H Vibration Test Type: Sine, Random, Classic Shock, Etc.
High Light:

environmental test chambers

,

environmental testing equipment


High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber









Combined environmental test equipment integrated temperature, humidity, vibration of the three functions of the test box.With rapid temperature change rate, temperature, and humidity integrated test environment and the vibration function.
Combined environmental test equipment provides the change of temperature and humidity environment for the aerospace, aviation, petroleum, chemical, electronics, communication and other scientific research and production units, at the same time in the test chamber electric vibration stress according to the provisions of the cycle is applied to the sample, for the user of the machine (or components), electrical appliances, instruments, materials etc. temperature and humidity, vibration stress screening test, in order to assess product adaptability or experiment on behavior evaluation.

.



Features

  •  Independent control system: can complete high temperature, low temperature, constant temperature, constant humidity, vibration test and integrated test.
  • Adopts portable track design to perform integrated or single element test easily.
  • Our vibration test systems are compatible with international test chambers of different brands. Labtone is in charge of assembly and provide the clients with integrated environment test system of different specifications and performance.



Specifications


Main Environment Temperature, Humidity, Vibration
Vibration Exciting Force 300kg.f~5000kg.f
Frequency range 2-3000Hz
Velocity  2.0 m/s
Displacement 50.8~100mmp-p
Chamber Inner Size 500x750x600 600x850x800 1000x1000x800 1000x1000x1000
Temperature Range -70 ~+150℃(Max.)
Humidity Range 20~98%R.H(Max.)
Type of Vibration Test Sine, Random, Classical Shock, Resonant search and dwell, sine plus random, random and random, etc.





Any special requirement please feel free to contact us and we will try to realize it.


Connection mode:

High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber 0
Vibration test systems and test chamber connect directly

High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber 1
Vibration test systems and test chamber connect through transition connector

High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber 2
Vibration test systems and test chamber connect through the table

High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber 3



Customer Services



Presales:

  • Technical consultation: test method, laboratory planning and suggestion.
  • Equipment selection: selection scheme, FAQ.
  • Product testing scheme.



In-Sales:

  • Customer communication and progress report.
  • Guidance for pre-installation preparation, equipment commissioning and test run.
  • Calibration (when Third Party’s verification is required).



After-Sales:

  • Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.
  • Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.
  • Technical support: special paid services are provided according to customer’s needs.
High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber 4High Stability Environmental Test Chamber Temperature Humidity Combined Vibration Chamber 5
