ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M

Certification
China Labtone Test Equipment Co., Ltd certification
China Labtone Test Equipment Co., Ltd certification
Customer Reviews
We are very pleased with the quality of service your company provides.

—— Dovbysh

We sincerely appreciate your responsiveness and the way you conduct business.

—— John

We have recommended your company to others because of our satisfaction with your service. We look forward to doing business with you for years to come

—— Alex

We are very satisfied with the quality of the tester!

—— Jochen

I'm Online Chat Now

ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M

ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M
ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M

Large Image :  ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M

Product Details:
Place of Origin: CHINA
Brand Name: LABTONE
Certification: CE ISO
Model Number: DT150
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: international wooden case
Delivery Time: 15-20 days
Payment Terms: T/T
Supply Ability: 50 Sets / Month

ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M

Description
Drop Height: 300-1500mm Specimen Weight: 85kg
Specimen Dimension: 800*800*800mm Drop Mode: Free Fall Drop
Machine Dimension: 1500*1000*2150mm Machine Weight: 480kg
Warranty: 12 Months Air Pressure: 0.5-0.7Mpa
High Light:

drop test equipment

,

drop weight impact testing machine

,

Package Drop Test Machine Payload 150lbs



ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M





Packaging drop test is used to determine the effect of impact on the package during use, transportation, loading and unloading. The strictly designed LABTONE “1G+” ensures its accuracy. Apart from accurate plane fall test, it can also perform edge drop and corner drop test to make a complete evaluation on the performance of packaging and product.


Specifications:


ModelDT150DT200
Drop height range (mm)300---1500300----2000
Specimen max.weight (kg)8585
Specimen max. size (mm)800*800*800800*800*800
Drop modeFreedom
Machine Dimension (mm)1500*1000*21501700*1200*2750
Machine weight (kg)480550
Power supplyAC220V 50Hz compressed air 0.5~0.7Mpa
StandardsISO2248-72(E) GB/T4857.5 JISZ0202-87 IEC68-2-27



Features:

  • Satisfy and even beyond GB, IEC, ASTM, ISTA and other industrial standards.
  • Can perform surfaces, corner and edge drops.
  • Precise guiding system and pneumatical driving
  • Unique swing arm structural design, escape acceleration of swing arm greater than 3G.
  • With double column guide, hydraulic buffer will absorb the dynamic force of the swing arm such that the movement is stable, reliable with low noise.
  • Self-locking screw in lifting mechanism to prevent accidental downward glide.
  • Automatic pneumatic interlocks to prevent abnormal detachment of swing arm.
  • Extensible support bracket and bottom slab.


Equipment Components


No.Part nameModelQty.Description
1MachineDT1501 set
2Control handle 1 set
3Auxiliary edge and angle clamps 1 set
4Connecting cable/duct hose 1 set



FAQ


1. Q: What is your warranty ?

  • 12 months product warranty. Free components will be provided if any performance failure occurs within 12 months caused by non-human damage.

2. Q: How-to vedio provided ?

  • Yes, if required, our engineers will record a specialize how-to video for you.

3. Q: Is the machine made in your own plant ?

  • Yes, welcome to visit our plant(factory), also we support OEM and ODM.

4. Q: What about the quality ?

  • Each instruments must be carried out 100% quality examination and test before shipping and delivery goods.
  • All of our machine are strictly according to CE & ISO standards.




Packaging

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case,which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless,moisture corrosion, good transparency etc


ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M 0

ISTA Package Drop Test Machine With Payload 150lbs Free-fall Drop Height 1.5M 1
